Rechargeable lipo battery 404246 3.7V 800mAh lithium-ion batteries for sale
Lipo battery Specification:
| Product Name | Lipo battery 404246 800mAh |
| Battery Type | Lithium polymer battery |
| PCM | yes | |
| Accembly Composed Type | 1S1p/ 1 cell | |
| Nominal Capacity | 800 mAh | @0.2C discharge |
| Nominal Voltage | 3.7 V | |
| Charge Voltage | 4.2±0.12 V | |
| Cut-off Voltage | 3.0 V | |
| Standard charge Current | 160mA | @0.2C charge |
| Max. charge current | 800 mA | @1C charge |
| Standard Discharge Current | 160 mA | @0.2C discharge |
| Max. Discharge Current | 800 mA | @1C discharge |
| Resistance | ＜20 mΩ | |
| Cycle Life: | Over 500 times | |
| Weight (Approx.) | 18 g | |
| Dimensions(T.W.L.) | 4.0*42*46 (mm) | |
| Charge Temperature | 0 ~ 45℃ | |
| Discharge Temperature | -20 ~ 60℃ | |
| Storage Temperature | -10~40℃ | Less than one month |
| 0~30℃ | More than one month |
| Protection Function(PCM) | Over charge, Over discharge,
Over load, Short Circuit |
| Warranty | 1 year from shipment date |
Advantage:
a.Fast delivery ,Top quality ;
b.First class after - sales service;
c.High energy density,Long cycle life;
d. Capacity, resistance, Voltage, platform time consistency is good;
e. With short-circuit production function, safe and reliable.
OEM/ODM service:
We have engineers, professional design team for your OEM service requirements. And we can design the products according to the specific requirements of the customers'.
Why choose us?
1.For all your inquires about us or our products,we will reply you in detail within 24 hours.
2.We own a well-trained and professional sales & after- sale services team who can speak fluent English language.
3.We offer OEM services,printing your own logo on product,customizing the retail box packing and other things.
4.We have very experienced R&D engineers and we have strong ability to do ODM projects.
5.Quality Control:100% of the products will be tested and doing ageing test to test its quality reliability.
FAQ:
Q: Are you manufacturer?
A: Yes, we are. You are warmly welcome to visit our factory if you have interest!
Q: Is OEM/ODM available?
A: Yes, it is. Please feel free to tell us your application and your basic battery requirements. Our R&D team will provide a full solution to your with these factors taken into consideration: working temperature, dimension, compound mode, power, capacity, peak current, PCM, fuse, motion control ICs, plug, etc.
Q: Can you provide samples?
A: Yes, we can. After discousion and designing with our sales and engineer, we encourage client to order samples to test our battery quality first.
Q: What safety protection function does the PCM have?
A: Short circuit protection, over-current protection,over-load protection, over-discharge protection, inversely-connection protection, temperature control, balance, fuse, thermistor, etc. Our engineer will choose particular function to use for your battery pack in accordance with your specific situation.
Q: Are there related certificates about battery?
A: If required, we could apply CE, ROHS, CB(IEC62133), UL, KC, PSE, BIS, UN38.3 etc.
|
|
